Name: Rexroth R900328797 Z2S16-1-51/ Z2S16-1-5X/ Pilot Operated Check Valve
Brand: Rexroth
SKU: R900328797 Z2S16-1-51/ Z2S16-1-5X/
Price: 1.00 USD
Availability: InStock
Rating: 4.5 (181 reviews)

Home Products Rexroth Hydraulic Valves

Rexroth R900328797 Z2S16-1-51/ Z2S16-1-5X/ Pilot Operated Check Valve

Product Details:

Place of Origin:	Germany
Brand Name:	Rexroth
Model Number:	R900328797 Z2S16-1-51/ Z2S16-1-5X/
CertifiSAARion:	ISO9001

Payment & Shipping Terms:

Minimum Order Quantity:	1
Price:	On request
Packaging Details:	Standard paper box
Delivery Time:	7-10days
Payment Terms:	T/T, Western Union
Supply Ability:	100PCS per month

Contact Now

Detailed Product Description

Model:

R900328797

MNR:

Z2S16-1-51/ Z2S16-1-5X/

High Light:

Rexroth Pilot Operated Check Valve

R900328797

300L/Min Rexroth Hydraulic Valves

Check valves, pilot operated Z2S16

Size 16
Component series 5X
Maximum operating pressure 315 bar
Maximum flow 300 l/min

Features
Sandwich plate valve for use in vertical stackings
Porting pattern according to ISO 4401-07-07-0-05
For the leakage-free blocking of one or two actuator ports, optional
Various cracking pressures
With pre-opening
Check valve installation sets available individually
Corrosion-protected design

Type Code:

01	02	03	04		05		06	07	08	09
Z2S	16			–	5X	/				*

01	Check valve, Sandwich plate design	Z2S
02	Size 16	16
Leakage-free blocking
03	In channel A and B	–
	In channel A	A
	In channel B	B
Cracking pressure
04	3 bar	1
	5 bar	2
	7,5 bar	3
	10 bar	4
05	Component series 50 ... 59 (50 ... 59: unchanged technical data and pin assignment)	5X
Seal material
06	NBR seals	no code
	FKM seals	V
	Observe compatibility of seals with hydraulic fluid used. (Other seals upon request)
Corrosion resistance (outside; thick film passivated according to DIN 50979 Fe//Zn8//Cn//T0)
07	None (valve housing primed)	no code
07	Improved corrosion protection (240 h salt spray test according to EN ISO 9227)	J3
Special version
08	Standard	no code
	Control open by external port G1/4 (only version "A" and "B")	SO40
	Control spool unloaded to port T	SO60
09	Further details in the plain text	*

SAAR specialized in pumps, motors, valves, bearings, couplings, gearbox, engine spare parts, filter elements, fittings, connectors, electronic components and accessories, mobile equiupment spare parts.

Rexroth Check valves, pilot operated Z2S16 Model List:

R900328797	Z2S16-1-5X/
R901402345	Z2S16-1-5X/=KM
R900535419	Z2S16-1-5X/J
R900085346	Z2S16-1-5X/ML
R900518562	Z2S16-1-5X/SO280
R900505825	Z2S16-1-5X/SO40
R900412459	Z2S16-1-5X/V
R901417166	Z2S16-1-5X/VJ3
R901299705	Z2S16-1-5X/VJ50
R900072647	Z2S16-1-5X=
R900401212	Z2S16-2-5X/
R900434675	Z2S16-2-5X/V
R900412346	Z2S16-3-5X/
R900412893	Z2S16-3-5X/V
R900442636	Z2S16-4-5X/
R900508670	Z2S16-4-5X/V
R900328798	Z2S16A1-5X/
R900525761	Z2S16A1-5X/J
R901318732	Z2S16A1-5X/SO18
R900518561	Z2S16A1-5X/SO280
R900061071	Z2S16A1-5X/SO30
R900407720	Z2S16A1-5X/V
R900402493	Z2S16A2-5X/
R900427329	Z2S16A2-5X/V
R900444118	Z2S16A3-5X/
R900085134	Z2S16A3-5X/V
R900566082	Z2S16A4-5X/
R900328799	Z2S16B1-5X/
R900446290	Z2S16B1-5X/V
R900477274	Z2S16B2-5X/
R900500092	Z2S16B2-5X/V
R900422295	Z2S16B3-5X/
R901168688	Z2S16B3-5X/V
R900539653	Z2S16B4-5X/
R901348885	Z2S16B4-5X/V
R971893714	Z2S16-1-5X/
R971893715	Z2S16-2-5X/
R971893710	Z2S16A1-5X/
R900427364	Z2S16A2-5X/V
R971893711	Z2S16B1-5X/
R971893712	Z2S16B1-5X/V
R971893713	Z2S16B2-5X/
