R901172257 4WRKE27E500L-3X/6EG24TK31/A5D3WC15M Rexroth 4WRKE27 Series Proportional Directional Valve

R901172257 4WRKE27E500L-3X/6EG24TK31/A5D3WC15M Rexroth 4WRKE27 Series Proportional Directional Valve

  • R901172257 4WRKE27E500L-3X/6EG24TK31/A5D3WC15M Rexroth 4WRKE27 Series Proportional Directional Valve
  • R901172257 4WRKE27E500L-3X/6EG24TK31/A5D3WC15M Rexroth 4WRKE27 Series Proportional Directional Valve
  • R901172257 4WRKE27E500L-3X/6EG24TK31/A5D3WC15M Rexroth 4WRKE27 Series Proportional Directional Valve
R901172257 4WRKE27E500L-3X/6EG24TK31/A5D3WC15M Rexroth 4WRKE27 Series Proportional Directional Valve
Product Details:
Place of Origin: Germany
Brand Name: Rexroth
Model Number: R901172257 4WRKE27E500L-3X/6EG24TK31/A5D3WC15M
CertifiSAARion: ISO9001
Payment & Shipping Terms:
Minimum Order Quantity: 1
Price: On request
Packaging Details: Standard paper box
Delivery Time: 7-10days
Payment Terms: T/T, Western Union
Supply Ability: 100PCS per month
Contact Now
Detailed Product Description
MNR: R901172257 MODEL: 4WRKE27E500L-3X/6EG24TK31/A5D3WC15M
High Light:

350 Bar Pressure Cut Off Valve

,

Hydraulic Rexroth Proportional Valve 4WRKE27

,

Directional Rexroth Control Valve

Rexroth 4WRKE Series Proportional Directional Valve

Size 10, 16, 25, 27, 32, 35
Component series 3X
Maximum operating pressure 350 bar
Maximum flow 3000 l/min

Features
*Pilot-operated 2-stage proportional directional valves with electrical position feedbackof the main control spool and integrated electronics (OBE) Control of flow direction and size
*Proportional solenoid operation
For subplate mounting: Porting pattern according to ISO 4401 Electrical position feedback
*Spring-centered main control spool Pilot control valve: single-stage proportional directional valve
*Main stage with position control

Type Code:
01
02
03
04
05
06

07

08
09
10
11

12
13
14
15
4
WRKE




‒
3X
/
6E
G24

K31
/

D3

*
01
4 main ports
4
02
Proportional directional valve with electrical position feedback and integrated electronics (OBE)
WRKE
03
Size 10
10

Size 16
16

Size 25
25

Size 27
27

Size 32
32

Size 35
35
04
Symbols; for the possible version, see "Symbols/Circuit diagrams"
E; E1-; E3-; W6-; W8-; R; R3; EA; W6A; EB; W6B
Rated flow NG10
05
25 l/min
25 1)
50 l/min
502)
100 l/min
100
Rated flow NG16
05
125 l/min
1252)
150 l/min
1502)
200 l/min
200
220 l/min
220
Rated flow NG25
05
220 l/min
220
350 l/min
350
Rated flow NG27
05
500 l/min
500
Size 32
05
400 l/min
400
600 l/min
600
Size 35
05
1000 l/min
1000
Characteristic curve form
06
Linear
L
Linear with fine control range
P
07
Component series 30 ... 39 (30 ... 39: unchanged installation and connection dimensions)
3X
08
Pilot control valve NG6
Proportional solenoid with detachable coil
6E
09
Supply voltage 24 V
G24
Pilot oil supply and return
10
External pilot oil supply, external pilot oil return
no code
Internal pilot oil supply, external pilot oil return
E
Pilot oil supply internal, pilot oil return internal
ET
External pilot oil supply, internal pilot oil return
T
Electrical connection
11
Without mating connector, connector according to DIN EN 175201-804
K31
Electrical interface
12
Command value/actual value ±10 mA
C1
Command value/actual value ±10 V
A1 3)
Command value/actual value ±10 V
A5
Command value/actual value 4 ... 20 mA
F1
13
With pressure reducing valve ZDR 6 DP0-4X/40YM-W80 (fixedly set)
D3
14
NBR seals
M
FKM seals
V
15
Further details in the plain text
*
1)
Only E and W6- with characteristic curve form L (linear) available

2)
Only E1- and W8- with characteristic curve form L (linear) available

3)
When replacing the component series 2X by 3X, the electronics interface A5 is to be defined (enable signal at pin C

SAAR specialized in pumps, motors, valves, bearings, couplings, gearbox, engine spare parts, filter elements, fittings, connectors, electronic components and accessories, mobile equiupment spare parts.

Rexroth 4WRKE27 Series Proportional Directional Valve​ on Sale, Short lead time, Best price!!!

R901025115 4WRKE27E500L-3X/6EG24EK31/A5D3M
R901172257 4WRKE27E500L-3X/6EG24TK31/A5D3WC15M
R901116067 4WRKE27Q1-500L-3X/6EG24K31/A1D3M
R901192918 4WRKE27W4-500P-3X/6EG24K31/A5D3M-182
R901109412 4WRKE27W500P-3X/6EG24EK31/A1D3M-877
R901124218 4WRKE27W500P-3X/6EG24K31/A1D3M-877
R901050041 4WRKE27W6-500L-3X/6EG24K31/A5D3V
R901057533 4WRKE27W8-500L-3X/6EG24EK31/A1D3M-280
R901052728 4WRKE27W8-500L-3X/6EG24EK31/A5D3V
R901148875 4WRKE27W8-500L-3X/6EG24EK31/C1D3M
R900747560 4WRKE27W8-500P-3X/6EG24K31/A5D3M-577
R900249274 4WRKE27E1-500L-3X/6EG24EK31/A1D3M
R901268865 4WRKE27E1-500L-3X/6EG24EK31/A1D3V
R900717642 4WRKE27E1-500L-3X/6EG24EK31/A5D3M
R900724347 4WRKE27E1-500L-3X/6EG24EK31/A5D3M-280
R901296528 4WRKE27E1-500L-3X/6EG24EK31/F1D3M
R901051417 4WRKE27E1-500L-3X/6EG24ETK31/A1D3M
R900249923 4WRKE27E1-500L-3X/6EG24K31/A1D3M
R901079320 4WRKE27E1-500L-3X/6EG24K31/A1D3V
R901040707 4WRKE27E1-500L-3X/6EG24K31/A5D3M
R901293038 4WRKE27E1-500L-3X/6EG24K31/A5D3M-280
R901229824 4WRKE27E1-500L-3X/6EG24K31/C1D3M
R901348665 4WRKE27E1-500L-3X/6EG24K31/F1D3M
R901548085 4WRKE27E1-500L-3X/6EG24K31/F1D3V
R901555462 4WRKE27E1-500P-3X/6EG24ETK31/F1D3M
R901224825 4WRKE27E1-500P-3X/6EG24K31/F1D3M
R901039097 4WRKE27E500L-3X/6EG24EK31/A1D3M
R901266055 4WRKE27E500L-3X/6EG24EK31/A1D3V
R901267566 4WRKE27E500L-3X/6EG24EK31/F1D3M
R901435011 4WRKE27E500L-3X/6EG24ETK31/F1D3M
R901092786 4WRKE27E500L-3X/6EG24K31/A1D3M
R901220391 4WRKE27E500L-3X/6EG24K31/A1D3M=XV
R901077093 4WRKE27E500L-3X/6EG24K31/A1D3V
R901549112 4WRKE27E500L-3X/6EG24K31/A1M-909
R901135347 4WRKE27E500L-3X/6EG24K31/A5D3M
R901057986 4WRKE27E500L-3X/6EG24K31/A5D3M-280
R901130165 4WRKE27E500L-3X/6EG24K31/C1D3M
R901133144 4WRKE27E500L-3X/6EG24K31/F1D3M
R901414322 4WRKE27E500L-3X/6EG24K31/F1D3V
R901210319 4WRKE27E500P-3X/6EG24ETK31/A1D3M
R901241021 4WRKE27E500P-3X/6EG24K31/A1D3M
R901264931 4WRKE27R3-500L-3X/6EG24EK31/A1D3M
R901266856 4WRKE27R3-500L-3X/6EG24K31/A1D3M
R901099052 4WRKE27R3-500L-3X/6EG24TK31/A1D3M
R901441366 4WRKE27R5-500L-3X/6EG24EK31/A1D3M-903
R901463313 4WRKE27W000L-3X/6EG24K31/A1D3M-A25
R901545842 4WRKE27W4-500L-3X/6EG24K31/A1D3M-A54
R901533811 4WRKE27W4-500L-3X/6EG24K31/A1D3M-A58
R900708992 4WRKE27W4-500L-3X/6EG24K31/A5D3M
R901550948 4WRKE27W500L-3X/6EG24K31/A1D3M-A76
R901303285 4WRKE27W500P-3X/6EG24ETK31/A5D3M-709=&
R901324993 4WRKE27W500P-3X/6EG24K31/A5D3M-709
R900710940 4WRKE27W500P-3X/6EG24K31/A5D3M-709=DE
R901041512 4WRKE27W6-500L-3X/6EG24EK31/A1D3M
R901220494 4WRKE27W6-500L-3X/6EG24EK31/A1D3M=XV
R901551918 4WRKE27W6-500L-3X/6EG24EK31/A1M-909
R900735040 4WRKE27W6-500L-3X/6EG24EK31/A5D3M
R901176012 4WRKE27W6-500L-3X/6EG24EK31/A5D3V-280
R901169415 4WRKE27W6-500L-3X/6EG24EK31/F1D3M
R901169989 4WRKE27W6-500L-3X/6EG24ETK31/A1D3M
R901216638 4WRKE27W6-500L-3X/6EG24ETK31/A1D3V
R900755687 4WRKE27W6-500L-3X/6EG24ETK31/A5D3M
R901213877 4WRKE27W6-500L-3X/6EG24ETK31/A5D3M535&
R901204539 4WRKE27W6-500L-3X/6EG24ETK31/F1D3M
R900731496 4WRKE27W6-500L-3X/6EG24K31/A1D3M
R901559292 4WRKE27W6-500L-3X/6EG24K31/A1D3M-259
R978916045 4WRKE27W6-500L-3X/6EG24K31/A1D3M43A1295
R901430698 4WRKE27W6-500L-3X/6EG24K31/A1D3M-772
R900616821 4WRKE27W6-500L-3X/6EG24K31/A5D3M
R901400201 4WRKE27W6-500L-3X/6EG24K31/A5D3M-280
R978916104 4WRKE27W6-500L-3X/6EG24K31/A5D3M43A1295
R901272383 4WRKE27W6-500L-3X/6EG24K31/A5D3M-535
R900702111 4WRKE27W6-500L-3X/6EG24K31/A5D3M-535=&
R901106202 4WRKE27W6-500L-3X/6EG24K31/A5D3M-871=&
R901313951 4WRKE27W6-500L-3X/6EG24K31/C1D3M
R901147944 4WRKE27W6-500L-3X/6EG24K31/F1D3M
R901209787 4WRKE27W6-500L-3X/6EG24TK31/A5D3M
R901329115 4WRKE27W6-500P-3X/6EG24K31/A1D3M
R900701429 4WRKE27W8-500L-3X/6EG24EK31/A1D3M
R900725366 4WRKE27W8-500L-3X/6EG24EK31/A5D3M
R900778594 4WRKE27W8-500L-3X/6EG24EK31/A5D3M-280
R901097952 4WRKE27W8-500L-3X/6EG24EK31/F1D3M
R901199286 4WRKE27W8-500L-3X/6EG24ETK31/A1D3M
R901126339 4WRKE27W8-500L-3X/6EG24ETK31/A5D3M
R901115085 4WRKE27W8-500L-3X/6EG24ETK31/F1D3M
R901250339 4WRKE27W8-500L-3X/6EG24ETK31/F1D3V
R900750794 4WRKE27W8-500L-3X/6EG24K31/A1D3M
R900706180 4WRKE27W8-500L-3X/6EG24K31/A5D3M
R901088135 4WRKE27W8-500L-3X/6EG24K31/A5D3M-535
R901023812 4WRKE27W8-500L-3X/6EG24K31/A5D3V
R901404792 4WRKE27W8-500L-3X/6EG24K31/C1D3M
R901072883 4WRKE27W8-500L-3X/6EG24K31/F1D3M
R901274300 4WRKE27W8-500L-3X/6EG24K31/F1D3V
R901051312 4WRKE27W8-500L-3X/6EG24TK31/A1D3M
R901083317 4WRKE27W8-500P-3X/6EG24K31/A5D3M
R901057319 4WRKE27W9-500L-3X/6EG24K31/A5D3M
