Name: R901321580 4WRTE27W8-500P-4X/6EG24K31/A5M Rexroth 4WRTE27 Series Valve
Brand: Rexroth
SKU: R901321580 4WRTE27W8-500P-4X/6EG24K31/A5M
Price: 1.00 USD
Availability: InStock
Rating: 5 (181 reviews)

Home Products Rexroth Hydraulic Valves

R901321580 4WRTE27W8-500P-4X/6EG24K31/A5M Rexroth 4WRTE27 Series Valve

Product Details:

Place of Origin:	Germany
Brand Name:	Rexroth
Model Number:	R901321580 4WRTE27W8-500P-4X/6EG24K31/A5M
CertifiSAARion:	ISO9001

Payment & Shipping Terms:

Minimum Order Quantity:	1
Price:	On request
Packaging Details:	Standard paper box
Delivery Time:	7-10days
Payment Terms:	T/T, Western Union
Supply Ability:	100PCS per month

Contact Now

Detailed Product Description

MNR:

R901321580

MODEL:

4WRTE27W8-500P-4X/6EG24K31/A5M

High Light:

Flexible Rexroth Directional Control Valve

A5M Rexroth Flow Control Valve

Hydraulic Rexroth Control Valve

Rexroth High-response directional valves, pilot operated, with electrical position feedbackand integrated electronics (OBE) 4WRTE

Size 10 … 35
Component series 4X
Maximum operating pressure 350 bar
Maximum flow 3000 l/min
Nominal flow 25 … 1000 l/min

Features
Reliable - proven and robust design
Safe
- Automatic pressure compensation in the control chambers of the main stage bythe pilot controlvalve
- Control spool of the main stage in the springcentered centralposition and/or in the offset position
- Optionally with spool position monitoring
Flexible - suitable for position, velocity and pressure control
Precise - high response sensitivity and little hysteresis

Type Code:

01	02	03	04	05	06	07	08		09		10	11	12	13		14	15	16	17
4	WRT	E						‒	4X	/	6E	G24		K31	/				*

01	4 main ports	4
02	High-response directional valve, pilot operated	WRT
03	With integrated electronics (OBE)	E
04	Without spool position monitoring	no code
04	With spool position monitoring (NG16 … NG35 only)	M
05	Size 10	10
	Size 16	16
	Size 25	25
	Size 27	27
	Size 32	32
	Size 35	35
06	Symbols; for the possible version, see "Symbols/Circuit diagrams"
Rated flow (Δp = 5 bar/control edge)
07	Size 10
	25l/min¹⁾	25
	50l/min²⁾	50
	90 l/min	100
	Size 16
	150l/min³⁾	150
	220l/min	220
	Size 25
	220l/min	220
	350 l/min	350
	Size 27
	500 l/min	500
	Size 32
	400 l/min	400
	600 l/min	600
	Size 35
	1000 l/min	1000
Flow characteristic
08	Linear	L
08	Linear with fine control range	P
09	Component series 40 … 49 (40 … 49: unchanged installation and mounting dimensions)	4X
Pilot control valve
10	Proportional solenoid with detachable coil (NG6)	6E
Power supply
11	Direct voltage 24 V	G24
Pilot oil flow
12	External pilot oil supply, external pilot oil return	no code
	Internal pilot oil supply, external pilot oil return	E
	Pilot oil supply internal, pilot oil return internal	ET
	External pilot oil supply, internal pilot oil return	T
Electrical connection
13	Without mating connector, connector according to DIN EN 175201-804	K31⁴⁾
Electrical interface
14	Command value/actual value ±10 V	A1
	Command value/actual value 4 … 20 mA	F1
	Command value/actual value ±10 V, enable signal (pin C)	A5⁵⁾
Seal material
15	NBR seals	M
15	FKM seals	V
16	Without electronics protection membrane	no code
16	With electronics protection membrane	-967
17	Further details in the plain text	*

¹⁾	Symbol E, W6-, W8- and V only with flow characteristic "L"
²⁾	Symbol E1-, W8- and V1 only with flow characteristic "L"
³⁾	Symbol V1 only with flow characteristic "L"
⁴⁾	Mating connectors, separate order, see "Accessories"
⁵⁾	When replacing the component series 3X by 4X, the electronics interface is to be defined with A5 (enable signal at pin C).

SAAR specialized in pumps, motors, valves, bearings, couplings, gearbox, engine spare parts, filter elements, fittings, connectors, electronic components and accessories, mobile equiupment spare parts.

Rexroth 4WRTE27 Series High-response Directional Valves on Sale, Short lead time, Best price!!!

R901069426	4WRTE 27 E500L-4X/6EG24ETK31/A5M
R901062317	4WRTE 27 E500L-4X/6EG24TK31/A5M
R901218944	4WRTE 27 R500L-4X/6EG24ETK31/A5M
R901119763	4WRTE 27 V1-500L-4X/6EG24ETK31/A5M
R901222177	4WRTE 27 V500L-4X/6EG24ETD/A5M-494
R901161070	4WRTE 27 V500P-4X/6EG24K31/A1M-650
R900772778	4WRTE 27 V500P-4X/6EG24K31/A1M-679
R900727362	4WRTE27E1-500L-4X/6EG24EK31/A1M
R901444957	4WRTE27E1-500L-4X/6EG24EK31/A1WB15M
R901225328	4WRTE27E1-500L-4X/6EG24EK31/A5M
R901339436	4WRTE27E1-500L-4X/6EG24EK31/A5V
R901380593	4WRTE27E1-500L-4X/6EG24ETK31/F1M
R901016732	4WRTE27E1-500L-4X/6EG24K31/A1M
R901447664	4WRTE27E1-500L-4X/6EG24K31/A1WB15M
R901356860	4WRTE27E1-500L-4X/6EG24K31/A5M
R901349435	4WRTE27E1-500L-4X/6EG24K31/F1M
R901427378	4WRTE27E1-500L-4X/6EG24TK31/A1M
R901117791	4WRTE27E1-500P-4X/6EG24EK31/A1M
R901174766	4WRTE27E500L-4X/6EG24EK31/A1M
R901254425	4WRTE27E500L-4X/6EG24EK31/F1M
R900976865	4WRTE27E500L-4X/6EG24ETK31/A1M
R900616822	4WRTE27E500L-4X/6EG24K31/A1M
R901469319	4WRTE27E500L-4X/6EG24K31/A1V
R900733934	4WRTE27E500L-4X/6EG24K31/A5M
R901137985	4WRTE27E500L-4X/6EG24K31/A5WB15M
R901349438	4WRTE27E500L-4X/6EG24K31/F1M
R901422545	4WRTE27E500L-4X/6EG24TK31/A1M
R901025779	4WRTE27E500P-4X/6EG24ETK31/A1M
R900967043	4WRTE27E500P-4X/6EG24K31/A1M
R901127618	4WRTE27E500P-4X/6EG24K31/A5M
R901526065	4WRTE27E500P-4X/6EG24K31/F1M
R901044502	4WRTE27E500P-4X/6EG24K31/F1WX00M-824
R901434920	4WRTE27Q2-500P-4X/6EG24ETK31/A5M
R901120326	4WRTE27Q2-500P-4X/6EG24K31/A1M
R900732448	4WRTE27Q2-500P-4X/6EG24K31/A5M
R901132052	4WRTE27Q2-500P-4X/6EG24K31/A5WB15M
R901050045	4WRTE27Q2-500P-4X/6EG24K31/A5WB16M
R900772655	4WRTE27R500L-4X/6EG24K31/A1M
R901006790	4WRTE27R5-500L-4X/6EG24TK31/A1M-737
R901000410	4WRTE27V000L-4X/6EG24K31/A1M-736
R900962047	4WRTE27V1-500L-4X/6EG24EK31/A1M
R901116051	4WRTE27V1-500L-4X/6EG24EK31/F1M
R901356557	4WRTE27V1-500L-4X/6EG24ETK31/A1M
R901180641	4WRTE27V1-500L-4X/6EG24ETK31/F1M
R901529548	4WRTE27V1-500L-4X/6EG24ETK31/F1M-967
R901310512	4WRTE27V1-500L-4X/6EG24K31/A1M
R901284895	4WRTE27V1-500L-4X/6EG24K31/A5M
R901349441	4WRTE27V1-500L-4X/6EG24K31/F1M
R901538052	4WRTE27V1-500L-4X/6EG24TK31/A1M
R901053683	4WRTE27V500L-4X/6EG24ETK31/A1M
R901309465	4WRTE27V500L-4X/6EG24ETK31/F1M
R900781687	4WRTE27V500L-4X/6EG24K31/A1M
R901287891	4WRTE27V500L-4X/6EG24K31/A1M-967
R900760147	4WRTE27V500L-4X/6EG24K31/A5M
R901110479	4WRTE27V500L-4X/6EG24K31/F1M
R901212549	4WRTE27V500P-4X/6EG24EK31/A1M
R901185058	4WRTE27V500P-4X/6EG24EK31/F1M
R901351160	4WRTE27V500P-4X/6EG24ETK31/F1M
R901033479	4WRTE27V500P-4X/6EG24K31/A1M
R901467071	4WRTE27W6-500L-4X/6EG24EK31/A1M
R901044540	4WRTE27W6-500L-4X/6EG24EK31/A5M
R901004563	4WRTE27W6-500L-4X/6EG24ETD/A5M-494
R978918550	4WRTE27W6-500L-4X/6EG24ETK31/A1M
R901055416	4WRTE27W6-500L-4X/6EG24ETK31/A1V
R901009115	4WRTE27W6-500L-4X/6EG24ETK31/A5M
R900244543	4WRTE27W6-500L-4X/6EG24ETK31/F1M
R900977345	4WRTE27W6-500L-4X/6EG24K31/A1M
R900737716	4WRTE27W6-500L-4X/6EG24K31/A1V
R978916171	4WRTE27W6-500L-4X/6EG24K31/A5M
R901349445	4WRTE27W6-500L-4X/6EG24K31/F1M
R901072889	4WRTE27W6-500L-4X/6EG24K31/F1V
R901051146	4WRTE27W8-500L-4X/6EG24EK31/A1M
R901359422	4WRTE27W8-500L-4X/6EG24EK31/F1M
R901485962	4WRTE27W8-500L-4X/6EG24ETK31/A1M
R901475343	4WRTE27W8-500L-4X/6EG24ETK31/F1M
R900977344	4WRTE27W8-500L-4X/6EG24K31/A1M
R901094203	4WRTE27W8-500L-4X/6EG24K31/A1V
R901162070	4WRTE27W8-500L-4X/6EG24K31/A5M
R901097371	4WRTE27W8-500L-4X/6EG24K31/F1M
R901403261	4WRTE27W8-500L-4X/6EG24K31/F1V
R901011153	4WRTE27W8-500P-4X/6EG24EK31/F1M
R901321580	4WRTE27W8-500P-4X/6EG24K31/A5M
