Rexroth A10VSO71DRS/32R-VPB22U99S2184

Rexroth A10VSO71DRS/32R-VPB22U99S2184

  • Rexroth A10VSO71DRS/32R-VPB22U99S2184
Rexroth A10VSO71DRS/32R-VPB22U99S2184
Product Details:
Place of Origin: Germany
Brand Name: Rexroth
Certification: ISO9001
Model Number: A10VSO71DRS/32R-VPB22U99S2184
Payment & Shipping Terms:
Minimum Order Quantity: 1
Packaging Details: Carton, Wooden box
Delivery Time: 7-10days
Payment Terms: T/T, Western Union
Supply Ability: 10PCS in 7-10days
Contact Now
Detailed Product Description
Material No.: R902449040 Type No.: A10VSO71DRS/32R-VPB22U99S2184
High Light:

Axial Piston Variable Pump

,

A10VSO71DRS

Axial Piston Variable Pump A10VSO Series 32



Optimized medium pressure pump for high power machines
Size 45 … 180
Nominal pressure 280 bar
Maximum pressure 350 bar
Open circuit



Features
Through drive for mounting of further pumps up to same nominal size
Approved for high speeds
Increased functional reliability
Hydrostatically relieved swashplate bearing
Large variety of controls
Low operating noise
Swashplate design



Table of values

Size 45 71 100 140 180
Displacement
geometric, per revolution
  Vg max cm³ 45 71 100 140 180
Nominal pressure   pnom bar 280 280 280 280 280
Maximum pressure   pmax bar 350 350 350 350 350
Maximum speed at Vg max nnom rpm 1800 1800 1800 1800 1800
Flow at Vg max and nnom qV nom l/min 81 128 180 252 324
at Vg max and n = 1500 rpm qV 1500 l/min 67.5 106.7 150 210 270
Power at qV nom and pnom P kW 38 59.7 84 118 151
at qV 1500 and pnom P 1500 kW 67.5 106.7 150 210 270
Torque at Vg max and pnom M Nm 200 317 446 624 802
Weight (approx.)   m kg 30 47 69 73 78



SAAR specialized in pumps, motors, valves, bearings, couplings, gearbox, engine spare parts, filter elements, fittings, connectors, electronic components and accessories, mobile equiupment spare parts.



 Axial Piston Variable Pump A10VSO Series 32 Model List:



R902469085 A10VSO100LA7S/32R-VSB22U99
R902469087 A10VSO140LA6S/32R-VSB22U99
R902452707 A10VSO45DFR1/32R-VPB12N00-S2655
R902530923 A10VSO45DRF/32R-VPB22U00E
R902494250 A10VSO45DRG/32R-VPB22U99
R902519912 A10VSO45DRG/32R-VSB22U00E
R902513630 A10VSO45DRS/32R-VSB32U00E
R902456829 A10VSO71DR/32R-VPB12N00
R902448636 A10VSO71DR/32R-VPB22U99
R902448638 A10VSO71DR/32R-VPB32U99
R902449985 A10VSO71DR/32R-VSB12N00
R902469696 A10VSO71DR/32R-VSB12N00-SO108
R902517131 A10VSO71DR/32R-VSB22U00S
R902478094 A10VSO71DR/32R-VSB22U04
R902452790 A10VSO71DR/32R-VSB22U99-S2174
R902463368 A10VSO71DRF/32R-VPB32U99
R902489530 A10VSO71DRG/32R-VPB12N00
R902557020 A10VSO71DRG/32R-VPB12N00C
R902540469 A10VSO71DRG/32R-VPB12N00-S1550
R902465463 A10VSO71DRG/32R-VPB22U99
R902448221 A10VSO71DRS/32R-VPB12N00
R902448900 A10VSO71DRS/32R-VPB12N00-S1439
R902448899 A10VSO71DRS/32R-VPB12N00-S1648
R902452789 A10VSO71DRS/32R-VPB22U99
R902452029 A10VSO71DRS/32R-VPB22U99-S1439
R902452429 A10VSO71DRS/32R-VPB22U99-S2183
R902452431 A10VSO71DRS/32R-VPB22U99-S2184
R902537562 A10VSO71DRS/32R-VPB32U00E-S2709
R902448836 A10VSO71DRS/32R-VPB32U99-S2026
R902494805 A10VSO71DRS/32R-VPB32U99-S2709
R902448179 A10VSO71DRS/32R-VPB32U99-SO52
R902486410 A10VSO71DRS/32R-VRB32U01-SO52
R902486409 A10VSO71DRS/32R-VRB32U68-SO52
R902450319 A10VSO71DRS/32R-VSB12N00-S1439
R902510280 A10VSO71DRS/32R-VSB22U00E-SO52
R902501798 A10VSO71DRS/32R-VSB22U99
R902512433 A10VSO71DRS/32R-VSB22UB3E-SO52
R902551878 A10VSO71LA6DG/32R-VSD72U00E
R902448742 A10VSO71LA6D/32R-VPB32U99
R902454852 A10VSO71LA6DS/32R-VPB22U99
R902454564 A10VSO71LA6DS/32R-VPB32U99
R902461698 A10VSO71LA6DS/32R-VSB22U99
R902463155 A10VSO71LA7S/32R-VPB22U99
R902463294 A10VSO71LA7S/32R-VPB32U99
R902436234 A10VSO100DFR1/32R-VPB12N00
R902449982 A10VSO100DR/32R-VPB12N00
R902444079 A10VSO100DR/32R-VPB12N00-SO13
R902469690 A10VSO100DR/32R-VPB32L60
R902460598 A10VSO100DR/32R-VPB32U99
R902490862 A10VSO100DR/32R-VSB12N00
R902448357 A10VSO100DRG/32R-VPB12N00
R902496845 A10VSO100DRG/32R-VPB22U00E
R902455406 A10VSO100DRG/32R-VSD32U07-S2879
R902451585 A10VSO100DRG/32R-VSB32U99
R902460602 A10VSO100DRS/32R-VPB12N00
R902436353 A10VSO100DRS/32R-VPB12N00-S1439
R902436863 A10VSO100DRS/32R-VPB12N00-SO32
R902531610 A10VSO100DRS/32R-VPB22U00E-SO32
R902452557 A10VSO100DRS/32R-VPB22U99-S1439
R902450320 A10VSO100DRS/32R-VPB22UB8-S1439
R902450323 A10VSO100DRS/32R-VPB22UB9-S1439
R902445577 A10VSO100DRS/32R-VPB32U99-S1440
R902445605 A10VSO100DRS/32R-VPB32U99-S2001
R902450324 A10VSO100DRS/32R-VSB12N00-S1439
R902452634 A10VSO100DRS/32R-VSB22UB8-S1439
R902451171 A10VSO100DRS/32R-VSB22UB9-S1439
R902454561 A10VSO100DRS/32R-VPB22U99
R902543383 A10VSO100DRS/32R-VPB32U00E-S2709
R902454560 A10VSO100DRS/32R-VPB32U99
R902477585 A10VSO100DRS/32R-VSB32U99
R902455762 A10VSO100LA6D/32R-VPB32U99
R902454864 A10VSO100LA6DS/32R-VPB22U99
R902454866 A10VSO100LA6DS/32R-VPB32U99
R902492533 A10VSO100LA7D/32R-VSB32C10
R902468514 A10VSO100LA7DS/32R-VPB22U99
R902548587 A10VSO100LA7DS/32R-VSB32U00E
R902488378 A10VSO140DG/32R-VSB22U68
R902488534 A10VSO140DR/32R-CPB32U99-SO275
R902464808 A10VSO140DR/32R-VKD72U99
R902449984 A10VSO140DR/32R-VPB12N00
R902460597 A10VSO140DR/32R-VPB32U99
R902489334 A10VSO140DR/32R-VPB32UB7
R902497964 A10VSO140DR/32R-VPB32UB7E-S3973
R902485747 A10VSO140DR/32R-VSB12N00
R902531574 A10VSO140DR/32R-VSB12N00-SO108
R902497965 A10VSO140DR/32R-VSB32U00E-S3973
R902489335 A10VSO140DR/32R-VSB32U99
R902494857 A10VSO140DR1/32R-CPB32U99Z-S1804
R902463369 A10VSO140DRF/32R-VPB32U99
R902486850 A10VSO140DRF/32R-VPB32U99-S1550
R902462477 A10VSO140DRG/32R-VPB12N00
R902449671 A10VSO140DRG/32R-VPB22U99-SO488
R902449250 A10VSO140DRG/32R-VPB32U99-SO488
R902455405 A10VSO140DRG/32R-VSD32U07-S2100
R902445697 A10VSO140DRG/32R-VSD32U68-S2100
R902513544 A10VSO140DRG/32R-VSD72U00E
R902448219 A10VSO140DRS/32R-VPB12N00
R902448360 A10VSO140DRS/32R-VPB22U68
R902465472 A10VSO140DRS/32R-VPB22U99
R902496218 A10VSO140DRS/32R-VPB22UB3E
R902450364 A10VSO140DRS/32R-VPB22UB8
R902450356 A10VSO140DRS/32R-VPB22UB9
R902448363 A10VSO140DRS/32R-VPB32U68
R902446190 A10VSO140DRS/32R-VPB32U99
R902450880 A10VSO140DRS/32R-VPB32U99-S2117
R902450706 A10VSO140DRS/32R-VSB12N00
R902477257 A10VSO140DRS/32R-VSB22U68
R902450853 A10VSO140DRS/32R-VSB22U99
R902450808 A10VSO140DRS/32R-VSB22UB7
R902452628 A10VSO140DRS/32R-VSB22UB8
R902452631 A10VSO140DRS/32R-VSB22UB9
R902450852 A10VSO140DRS/32R-VSB32U99
R902514124 A10VSO140DRS/32R-VSD72U00E
R902482706 A10VSO140LA6D/32R-VPB22U68
R902449059 A10VSO140DRS/32R-VPB22U99
R902530948 A10VSO180DR/32R-VPB22U00E
R902557409 A10VSO180DR/32R-VSB12N00E
R902534337 A10VSO180DRF/32R-VSD72U00E
R902516851 A10VSO180DRF/32R-VPB22U00E
R902497939 A10VSO180DRG/32R-VKD72U00EE
R902492780 A10VSO180DRG/32R-VPB22H00
R902540895 A10VSO180DRG/32R-VPB22U00E
R902486825 A10VSO180DRG/32R-VPB22U99
R902540343 A10VSO180DRS/32R-VPB32U00E
R902547457 A10VSO180LA7DS/32R-VPB22U00E
R902545827 A10VSO180LA7DS/32R-VSB32U00E
R902544613 A10VSO180LA7DS/32R-VSB32U00E
R902497334 A10VSO180LA7DS/32R-VSB32U00E
R902546015 A10VSO180LA8DS/32R-VSB32U00E
R902516161 A10VSO180LA8DS/32R-VSB32U00E
R987124868 A10VSO100DRS/32R-VPB32U99
R902436233 ALA10VSO100DFR1/32R-VPB12N00
R902436233 ALA10VSO100DFR1/32R-VPB12N00
R902533294 ALA10VSO100DR/32R-VPB12N00
R902533294 ALA10VSO100DR/32R-VPB12N00
R902486086 ALA10VSO140DR/32R-VPB12N00
R902486086 ALA10VSO140DR/32R-VPB12N00
