A6VE Variable Plug-In Motor R902403883 ALA6VE250EZ2/63W2-VZM020B

A6VE Variable Plug-In Motor R902403883 ALA6VE250EZ2/63W2-VZM020B

  • A6VE Variable Plug-In Motor R902403883 ALA6VE250EZ2/63W2-VZM020B
  • A6VE Variable Plug-In Motor R902403883 ALA6VE250EZ2/63W2-VZM020B
A6VE Variable Plug-In Motor R902403883 ALA6VE250EZ2/63W2-VZM020B
Product Details:
Place of Origin: Germany
Brand Name: Rexroth
Model Number: R902403883 ALA6VE250EZ2/63W2-VZM020B
CertifiSAARion: ISO9001
Payment & Shipping Terms:
Minimum Order Quantity: 1
Price: On Request
Packaging Details: Standard Wooden Box
Delivery Time: 7-10days
Payment Terms: T/T, Western Union
Supply Ability: 1000/Month
Contact Now
Detailed Product Description
MNR: R902403883 Model No.: ALA6VE250EZ2/63W2-VZM020B
High Light:

A6VE Variable Plug-In Motor

,

High Pressure Motor Bent Axis

,

Plug-In Motor High Torque 450 Bar

Axial piston variable motor A6VE series 6X

High pressure motor for integration in mechanical gearboxes
Series 65: size 55 … 200
series 63: size 28, 250
Nominal pressure up to 400 bar
Maximum pressure up to 450 bar
Open and closed circuits

Features
Space-saving construction due to recessed mounting flange
Easy to install, simply slide into the mechanical gearbox
Wide control range (can be swiveled to zero)
Approved for very high speeds
High torque
Optional with attached flushing and boost-pressure valve
Optional with integrated or attached counterbalance valve
Bent-axis design

Table of values
Size
28
55
80
107
160
200
250
Series
63
65
65
65
65
65
63
Displacement

Vg max
cm³
28.1
54.8
80
107
160
200
250
Vg x
cm³
18
35
51
68
61
76
188
Vg min
cm³
0
0
0
0
0
0
0
Nominal pressure

pnom
bar
400
400
400
400
400
400
350
Maximum pressure

pmax
bar
450
450
450
450
450
450
400
Maximum speed
at Vg max 1)
nnom
rpm
5550
4450
3900
3550
3100
2900
2700
at Vg < Vg x
nmax
rpm
8750
7000
6150
5600
4900
4600
3300
at Vg min
nmax 0
rpm
10450
8350
7350
6300
5500
5100
3300
Inlet flow 2)
at Vg max and nnom
qV nom
l/min
156
244
312
380
496
580
675
Torque
at Vg max and pnom
M
Nm
179
349
509
681
1019
1273
1391
Weight (approx.)

m
kg
16
28
36
46
62
78
110

SAAR specialized in pumps, motors, valves, bearings, couplings, gearbox, engine spare parts, filter elements, fittings, connectors, electronic components and accessories, mobile equiupment spare parts.

Axial piston variable motor A6VE28 series 6X on Sale, Short lead time, Best price!!!

R902480869 AA6VE250EP2/63W1-VZM150B
R902476523 AA6VE250EP2/63W2-VZM088B-SO216
R902582577 AA6VE250EP2D/63W1-VZM020BC
R902539394 AA6VE250EP2D/63W1-VZM020BE
R902574098 AA6VE250EP2D/63W1-VZM020HB
R902572086 AA6VE250EP2D/63W1-VZM027FB
R902537486 AA6VE250EP2D/63W1-VZM027FB-SO154
R902573213 AA6VE250EP2D/63W2-VZM020B
R910975544 AA6VE250EZ2/63W2-VZM020B
R902580110 AA6VE250EZ2/63W2-VZM027B
R902431956 AA6VE250EZ2/63W2-VZM027DB-SO179
R902412559 AA6VE250EZ2/63W2-VZM088B-SO144
R902434496 AA6VE250EZ2/63W2-VZM088DB-SO180
R910989642 AA6VE250HA1/63W1-VZM020A
R902415644 AA6VE250HA1/63W1-VZM027A
R902485247 AA6VE250HA1/63W2-VZM020A
R910984718 AA6VE250HA1/63W2-VZM020A
R910990600 AA6VE250HA1/63W2-VZM027A
R902541611 AA6VE250HA1/63W2-VZM027AE
R902420177 AA6VE250HA1T/63W1-VZM027A
R902489507 AA6VE250HA1T/63W1-VZM088A-SO144
R902514041 AA6VE250HA1T/63W1-VZM088A-SO144
R902512184 AA6VE250HA1T/63W1-VZM388A-SO75
R902492752 AA6VE250HA1T/63W2-VZM027A
R902489288 AA6VE250HA1T/63W2-VZM088A-SO144
R902448954 AA6VE250HA2/63W2-VZM027A
R902511374 AA6VE250HA2T/63W1-VZM017A
R902454123 AA6VE250HA2T/63W1-VZM027A
R902468580 AA6VE250HA2T/63W2-VZM020AE
R902477203 AA6VE250HA2T/63W2-VZM020AE
R902479517 AA6VE250HA2T/63W2-VZM027AE
R902406701 AA6VE250HD1/63W1-VZM027BESO98
R910970771 AA6VE250HD1/63W1-VZM027B-SO98
R910983892 AA6VE250HD1/63W1-VZM027B-SO107
R902492188 AA6VE250HD1/63W1-VZM027DB
R902510254 AA6VE250HD1/63W1-VZM027FB
R902512296 AA6VE250HD1/63W1-VZM150B
R902417987 AA6VE250HD1/63W2-VZM020B
R902542261 AA6VE250HD1/63W2-VZM027A
R902461552 AA6VE250HD1D/63W1-VZM088B-SO172
R910974042 AA6VE250HD1D/63W2-VZM020B
R902515239 AA6VE250HD2/63W1-VZM020DB-SO154
R902564456 AA6VE250HD2/63W1-VZM027BE
R902559471 AA6VE250HD2/63W2-VZM020BE
R902539449 AA6VE250HD2D/63W1-VZM010B
R902466597 AA6VE250HD2D/63W2-VZM020B
R902517201 AA6VE250HD2D/63W2-VZM020BE
R902558170 AA6VE250HD2D/63W2-VZM020BE
R902408649 AA6VE250HZ/63W1-VZM020B
R902519832 AA6VE250HZ/63W1-VZM020B-SO101
R902434547 AA6VE250HZ/63W1-VZM027B
R902478242 AA6VE250HZ/63W1-VZM027DB-SO154
R902572924 AA6VE250HZ/63W1-VZM027HB
R902516093 AA6VE250HZ/63W1-VZM088B-SO144
R902451307 AA6VE250HZ/63W1-VZM088B-SO172
R902515201 AA6VE250HZ/63W1-VZM388BESO232
R902513172 AA6VE250HZ/63W1-VZM388B-SO232
R902541154 AA6VE250HZ/63W2-VZM010B
R902470194 AA6VE250HZ/63W2-VZM020A
R902544157 AA6VE250HZ/63W2-VZM027A
R902405140 AA6VE250HZ/63W2-VZM027B
R902406634 AA6VE250HZ/63W2-VZM027BE
R902519834 AA6VE250HZ/63W2-VZM027BE
R902534483 AA6VE250HZ/63W2-VZM027DBESO154
R902512669 AA6VE250HZ/63W2-VZM027DB-SO154
R902571178 AA6VE250HZ/63W2-VZM027FB
R902553727 AA6VE250HZ/63W2-VZM027FBESO275
R902409549 AA6VE250HZ/63W2-VZM088B-SO144
R902423319 AA6VE250HZ/63W2-VZM088B-SO172
R902480236 AA6VE250HZ/63W2-VZM088B-SO172
R902519831 AA6VE250HZ/63W2-VZM088B-SO172
R902465172 AA6VE250HZ/63W2-VZM150B
R902570565 AA6VE250HZ/63W2-VZM388BESO232
R902512291 AA6VE250HZ/63W2-VZM388B-SO232
R902519091 AAA6VE250HA2T/63W1-VSM527FA-SO154
R910999233 AAA6VE250HZ/63W2-VSM017B-SO133
R910969142 AAA6VE250HZ/63W2-VSM089B-SO96
R902431311 AA6VE250EZ2/63W2-VZM027DB-SO154
R902460762 AA6VE250HD1D/63W1-VZM027B
R910988285 AA6VE250HZ/63W1-PZM020B
R910944150 AA6VE250HZ/63W2-PZM020B
R910946611 AA6VE250HZ/63W2-PZM027B
R910994582 AA6VE250HZ/63W2-VZM020B
R910975539 AAA6VE250EZ2/63W2-VZM527B-SO102
R910983642 AAA6VE250HD1/63W2-VZM527B-SO102
R902480867 ALA6VE250EP2/63W1-VZM150B
R902476521 ALA6VE250EP2/63W2-VZM088B-SO216
R902572087 ALA6VE250EP2D/63W1-VZM027FB
R902573212 ALA6VE250EP2D/63W2-VZM020B
R902403883 ALA6VE250EZ2/63W2-VZM020B
R902580109 ALA6VE250EZ2/63W2-VZM027BE
R902519680 ALA6VE250HD1/63W1-VZM027DBE
R902510252 ALA6VE250HD1/63W1-VZM027FBE
R902512294 ALA6VE250HD1/63W1-VZM150B
R902466893 ALA6VE250HD2D/63W2-VZM020B
R902408648 ALA6VE250HZ/63W1-VZM020B
R902543523 ALA6VE250HZ/63W2-VZM027B
R902571175 ALA6VE250HZ/63W2-VZM027FBE
R902409547 ALA6VE250HZ/63W2-VZM088B-SO144
R902423192 ALA6VE250HZ/63W2-VZM088B-SO172
R902512338 ALA6VE250HZ/63W2-VZM388B-SO232
R910990634 ALA6VE250HZ/63W1-PZM020B
R910990636 ALA6VE250HZ/63W2-PZM020B
R902543432 ALAA6VE250HA2T/63W1-VSM527FA-SO154
R910998016 ALAA6VE250HZ/63W2-VSM017B-SO133
R910969154 ALAA6VE250HZ/63W2-VSM089B-SO*G*
