Name: R928005997 1.0630PWR3-A00-0-M Rexroth Filter Elements
Brand: Rexroth
SKU: R928005997 1.0630PWR3-A00-0-M
Rating: 4.5 (188 reviews)

Home Products Rexroth Filter Element

R928005997 1.0630PWR3-A00-0-M Rexroth Filter Elements

Product Details:

Place of Origin:	Germany
Brand Name:	Rexroth
Model Number:	R928005997 1.0630PWR3-A00-0-M

Payment & Shipping Terms:

Minimum Order Quantity:	1
Price:	On request
Packaging Details:	Standard paper box
Delivery Time:	7-10days
Payment Terms:	T/T, Western Union
Supply Ability:	100PCS per month

Contact Now

Detailed Product Description

MNR:

R928005997

MATERIAL:

1.0630PWR3-A00-0-M

High Light:

1.0630PWR3-A00-0-M Rexroth Filter Elements

Rexroth Oil Filter Element

Cleanable Rexroth Return Line Filter

Rexroth Type 1.0 Filter Elements

Size 0040 … 2500
Pressure differential 330 bar
Filter rating 1 µm
Filter area 4.8 m²
Operating temperature range -10 … +100 °C

Features
▶▶ Filter media for numerous appliSAARion ranges made of
glass fiber material, filter paper, wire mesh, fleece
material and metal fiber fleece
▶▶ Cleanable wire mesh filter media
▶▶ Attainable oil cleanliness up to ISO 12/8/3 (ISO 4406)
▶▶ High dirt holding capacity and filtration performance
due to multi-layer glass fiber technology and simultaneously
a low initial pressure differential (ISO 3968)
▶▶ Extended product range for non-mineral oil
based fluids
▶▶ Filter elements with high pressure differential stability

Technical data

General

Type			1.	1.	1.	1.	1.	1.	1.	1.	1.	1.	1.	1.	1.	1.	1.	1.	1.
Size			0040	0063	0100	0160	0250	0400	0630	1000	0045	0055	0120	0130	0150	0200	0270	2000	2500
Weight ¹⁾		m	0.16 kg	0.24 kg	0.38 kg	0.74 kg	1.07 kg	1.48 kg	2.42 kg	3.44 kg				0.59 kg	0.67 kg			4.8 kg	9.14 kg
Filter rating / mesh size			1 µm
Filter area			4.8 m²
Ambient temperature range			-10 … +65 °C
Operating temperature range			-10 … +100 °C
Storage temperature range ²⁾	NBR		-40 ... +65 °C
Storage temperature range ²⁾	FKM		-20 ... +65 °C
Material	Cover of the filter element		Polyamide or tin-coated steel or tin-coated aluminum
	Base of the filter element		Polyamide or tin-coated steel or tin-coated aluminum
	Support tube of the filter element		Tin-coated steel
	Seals		NBR / FKM

General

Type			1.	1.	1.	1.	1.	1.	1.	1.	1.	1.	1.	1.	1.	1.	1.	1.	1.
Size			0040	0063	0100	0160	0250	0400	0630	1000	0045	0055	0120	0130	0150	0200	0270	2000	2500
Weight ¹⁾		m	0.16 kg	0.24 kg	0.38 kg	0.74 kg	1.07 kg	1.48 kg	2.42 kg	3.44 kg				0.59 kg	0.67 kg			4.8 kg	9.14 kg
Filter rating / mesh size			1 µm
Filter area			4.8 m²
Ambient temperature range			-10 … +65 °C
Operating temperature range			-10 … +100 °C
Storage temperature range ²⁾	NBR		-40 ... +65 °C
Storage temperature range ²⁾	FKM		-20 ... +65 °C
Material	Cover of the filter element		Polyamide or tin-coated steel or tin-coated aluminum
	Base of the filter element		Polyamide or tin-coated steel or tin-coated aluminum
	Support tube of the filter element		Tin-coated steel
	Seals		NBR / FKM

¹⁾	refers to non-woven glass fiber media
²⁾	max. relative air humidity 65 %

¹⁾	refers to non-woven glass fiber media
²⁾	max. relative air humidity 65 %

Hydraulic

Size	0040	0063	0100	0160	0250	0400	0630	1000	0045	0055	0120	0130	0150	0200	0270	2000	2500
Filtration direction	From the outside to the inside
Maximum pressure differential	330 bar
Minimum conductivity of the medium	300 pS/m
Hydraulic fluid temperature range	-10 … +100 °C

Hydraulic

Size	0040	0063	0100	0160	0250	0400	0630	1000	0045	0055	0120	0130	0150	0200	0270	2000	2500
Filtration direction	From the outside to the inside
Maximum pressure differential	330 bar
Minimum conductivity of the medium	300 pS/m
Hydraulic fluid temperature range	-10 … +100 °C

Important information on hydraulic fluids!

For more information and data on the use of other hydraulic fluids, please refer to data sheet 90220 or contact us!

Flame-resistant – containing water: Due to possible chemical reactions with materials or surface coatings of machine and system components, the service life with these hydraulic fluids may be less than expected. Filter materials made of filter paper P must not be used, filter elements with glass fiber material have to be used instead.

Bio-degradable: If filter materials made of filter paper are used, the filter life may be shorter than expected due to material incompatibility and swelling.

For appliSAARions outside these parameters, please consult us!

Hydraulic fluid		ClassifiSAARion	Suitable sealing materials	Suitable adhesive	Standards
Mineral oil		HLP	NBR	Standard	DIN 51424
Bio-degradable	Insoluble in water	HETG	NBR		VDMA 24568
	Insoluble in water	HEES	FKM		VDMA 24568
	Soluble in water	HEPG	FKM		VDMA 24568
Flame-resistant	Water-free	HFDU, HFDR	FKM		VDMA 24317
	Containing water	HFAS	NBR		DIN 24320
		HFAE	NBR		DIN 24320
		HFC	NBR		VDMA 24317
	Skydrol	‒	EPDM	Special “H”	‒

SAAR specialized in pumps, motors, valves, bearings, couplings, gearbox, engine spare parts, filter elements, fittings, connectors, electronic components and accessories, mobile equiupment spare parts.

Rexroth Type 1.0270 1.0400 1.0630 Size Filter Elements on Sale, Short lead time, Best price!!!

R928005999	1.0630PWR10-A00-0-M
R928055672	1.0630PWR10-A00-0-M/DN
R928006017	1.0630PWR10-A00-0-V
R928007855	1.0630PWR10-AH0-0-M
R928007873	1.0630PWR10-AH0-0-V
R928006008	1.0630PWR10-C00-0-M
R928006026	1.0630PWR10-C00-0-V
R928007864	1.0630PWR10-CH0-0-M
R928007882	1.0630PWR10-CH0-0-V
R928056885	1.0630PWR10-T00-0-M
R928006000	1.0630PWR20-A00-0-M
R928055670	1.0630PWR20-A00-0-M/DN
R928006018	1.0630PWR20-A00-0-V
R928007856	1.0630PWR20-AH0-0-M
R928007874	1.0630PWR20-AH0-0-V
R928006009	1.0630PWR20-C00-0-M
R928006027	1.0630PWR20-C00-0-V
R928007865	1.0630PWR20-CH0-0-M
R928007883	1.0630PWR20-CH0-0-V
R928056902	1.0630PWR20-T00-0-M
R928005997	1.0630PWR3-A00-0-M
R928036012	1.0630PWR3-A00-0-M/HY
R928006015	1.0630PWR3-A00-0-V
R928007853	1.0630PWR3-AH0-0-M
R928007871	1.0630PWR3-AH0-0-V
R928006006	1.0630PWR3-C00-0-M
R928006024	1.0630PWR3-C00-0-V
R928007862	1.0630PWR3-CH0-0-M
R928007880	1.0630PWR3-CH0-0-V
R928056903	1.0630PWR3-T00-0-M
R928005998	1.0630PWR6-A00-0-M
R928055671	1.0630PWR6-A00-0-M/DN
R928006016	1.0630PWR6-A00-0-V
R928007854	1.0630PWR6-AH0-0-M
R928007872	1.0630PWR6-AH0-0-V
R928006007	1.0630PWR6-C00-0-M
R928006025	1.0630PWR6-C00-0-V
R928007863	1.0630PWR6-CH0-0-M
R928007881	1.0630PWR6-CH0-0-V
R928056904	1.0630PWR6-T00-0-M
